An Overview of Radar Signal Processing

Radar signal processing lies at the heart of modern sensing and surveillance systems, enabling the detection, tracking, and classification of objects across diverse environments. This talk introduces the core concepts and techniques that underpin radar operation, with a focus on the basics engineers need to understand how these systems detect, locate, and track objects.

Topics will include waveform generation, pulse compression, matched filtering, Doppler processing, and clutter mitigation. Designed for engineers new to radar or seeking a refresher, the session emphasizes intuitive explanations, signal processing aspects, and system-level insights. By the end, attendees will have a solid grasp of the radar signal chain and the essential tools used to extract meaningful information from reflected signals.

What this presentation is about and why it matters

This talk gives a compact, concept-driven tour of radar signal processing: how pulses are transmitted and received, how time-domain ("fast-time") processing gives range, how pulse-to-pulse ("slow-time") processing gives velocity, and how antenna arrays give direction. For engineers who work with DSP this matters because radar reuses the same fundamental tools you already know (sampling, complex/IQ signals, DFTs, matched filters, filtering and windowing), but applies them in a physical sensing context where timing, power, ambiguity, and geometry drive system trade-offs.

Practically, the material helps you reason about design choices you will meet in real systems: why pulse width and bandwidth affect range resolution, why long pulses can be pulse-compressed to get both energy and resolution, how PRF trades off unambiguous range and velocity, and how simple slow-time filters (MTI) or DFT-based pulse-Doppler processing extract moving targets from clutter. These are core ideas for radar in automotive, aerospace, weather, remote sensing, industrial sensing, and emerging mmWave/IoT applications.

Who will benefit the most from this presentation

• DSP or communications engineers new to radar who want a high-level, signal-processing view of the radar chain.
• Students or researchers who need a quick map of pulse radar, pulse compression, Doppler processing, and array-based direction finding.
• SDR and embedded engineers implementing radar prototypes (understanding ADC/IQ choices, PRF, and processing blocks).
• System engineers who must trade off range/velocity/angle performance and understand ambiguity and blind-zone issues.
• Anyone who already knows sampling, complex baseband, and DFTs and wants to map those tools to radar problems.

What you need to know

Helpful background (short checklist):

• Complex/IQ sampling: radar receivers output complex samples (I + jQ). Know how analytic signals represent amplitude and phase, and why phase across pulses encodes Doppler (velocity).
• Sampling and bandwidth: Nyquist sampling applies to the pulse spectrum. Fast-time sample rate should exceed the signal bandwidth so you capture the waveform needed for matched filtering.
• Matched filtering and autocorrelation: matched filtering maximizes SNR and produces an output equal to the autocorrelation of the transmit pulse — this determines uncompressed range response.
• Range basics: range is obtained from two-way delay. If an echo delay is $\tau$, then range $R$ satisfies $R = c\tau / 2$ (where $c$ is speed of light). The raw range resolution of an unmodulated rectangular pulse of duration $\tau$ is $\Delta R_{\text{rect}} = c\tau / 2$.
• Pulse compression: long, energy-rich pulses can be modulated (LFM chirps or phase codes) so the matched-filtered output is narrow. For an LFM/chirped pulse with bandwidth $B$ the compressed-range resolution is $\Delta R_{\text{LFM}} = c/(2B)$; the processing gain is roughly the time–bandwidth product $TB=\tau B$.
• PRF, PRI, and ambiguity: PRF = $1/$PRI. If echoes return after the next pulse was transmitted, range ambiguity occurs. Unambiguous range approximates $R_{\text{unamb}}\approx c\cdot\text{PRI}/2$. PRF also sets slow-time sampling for Doppler and therefore unambiguous velocity.
• Doppler & velocity: Doppler frequency relates to radial velocity by $v = f_D \lambda / 2$. When you collect $M$ coherent pulses and take a DFT across them, Doppler bin width is $\Delta f = 1/(M\cdot\text{PRI})$ and velocity resolution $\Delta v = \lambda /(2 M \cdot \text{PRI})$.
• MTI vs. pulse-Doppler: simple MTI (e.g., one-pulse canceller) suppresses stationary clutter via slow-time differencing. Pulse-Doppler uses an FFT across pulses to estimate Doppler spectra and resolve multiple moving targets at the same range bin.
• Array processing: an antenna array samples spatially; phase differences across elements form a spatial sinusoid (steering vector) and allow angle estimation via FFT/beamforming or higher-resolution methods. Angle and Doppler relations are mathematically analogous (phase gradient across space vs. time).
• Data structures: expect the radar data matrix (fast-time × slow-time) and the radar data cube when antennas add a third dimension. Each row is a range bin; columns are pulse indices; the third dimension is antenna index.

Glossary

• Pulse Width (τ) - Time duration of a transmitted pulse; influences raw range resolution and minimum detectable range.
• PRI / PRF - Pulse Repetition Interval (time between pulses) and Pulse Repetition Frequency (1/PRI); key to unambiguous range and Doppler sampling.
• Range bin / range cell - A discrete range sample after matched filtering; each corresponds to a small interval of delay (distance).
• Matched filter - A filter matched to the transmit waveform that maximizes SNR and yields the waveform autocorrelation at the output.
• Pulse compression - Modulating a long pulse (chirp or code) so the matched-filter output is narrow: high energy + fine resolution.
• Chirp / LFM - Linear frequency modulation where instantaneous frequency sweeps linearly over time; widely used for pulse compression.
• Doppler - Frequency shift due to target radial velocity; extracted across pulses (slow-time) to estimate speed.
• MTI (Moving Target Indication) - A slow-time filter (often differencing) that suppresses stationary clutter to highlight moving targets.
• Ambiguity - Range or velocity aliases that occur when echoes or Doppler exceed the sampling interval set by PRI/PRF.
• Beamforming / steering vector - Spatial processing using phase differences across an array to form directional responses and estimate angles of arrival.
